Professional HEAVY DUTY Power Supply @ 30 Amps / 18 channels / Up to 2.5 Amps by channel Output / Overload Protection / Noise Filter per Channel / UL Certified
Top Highlights:
- Variable Output up to 15 VDC for Long Distance Camera Installations
- Compatible With Analog and Turbo HD Camera Systems
- Over-Voltage and Electrical Noise Protection on All Channels
- Fanless Convection Cooling System for Silent Operation
- Individual LED Indicators for Each of the 18 Output Channels
- Built-In EMI Filter Reduces Electromagnetic Interference... more info
Model:
XP18DC30HD
Brand: EPCOM POWERLINE
Warranty: 5 years
Contact your Sales Executive to obtain your first password.
EPCOM Certified Products
We test, inspect and restore all EPCOM products to working conditions.
| Stock | Classification | Your Price |
|---|
/DS7308HGHISH-l-p.png)
/E4KTURBOGEN3(LA)-p.PNG)
/WD43PURZ/WD43PURZ-p.PNG)
Optional Accessories
Product Specifications
P18DC20HD is the only POWER SUPPLY in the industry with variable output voltage up to 15VDC ensures voltage sending in long distances.
Compatible with full line of analog and EPCOM TURBO HD cameras.
Power output filtered to prevent noise and protected against overvoltage.
HEAVY-DUTY.
• Easy installation
• Short circuit and over-voltage protection.
• Conventionally cooling system air.
• External LED indicators for each channel output.
• Built against electromagnetic interference filter EMI.
Protection:
• Overcurrent protection: 105 ~ 150% (rated output voltage)
• Overvoltage Protection: 1.5 times of the rated voltage
• Short circuit protection: short the output voltage, with automatic reset.
Physical and Electrical Specifications:
• Approved by: IEC / EN / CSA, 60950 GB4943
• Input voltage: 100 o 240 Vac
• Output voltage: 11.5 ~ 15 VDC. (adjustable)
• Output Current: 30 A
- Output Current by channel : 2.5 A
• Board distribution: 1 for connection of 18 cameras.
• Dimensions: 10.43 x 10.03 x 3.14"
• Operating temperature: -14 ~ 122 °F
• Weight: 5.5 lb - UL Certified
*1 Year Warranty
